Simkawa Fine Milling Precision Linear Rack DIN 8 Grade

Fine Milling Precision Linear Rack DIN 8 Grade

Name: Fine Milling Precision Linear Rack DIN 8 Grade
Brand: TSC Bro
Price: 50.0 USD
Availability: InStock

Type:

Module:

In stock and ready for shipping

Product Information

The side positioning surface of the linear rack is ground, the gear rack has high precision, which can ensure the basic accuracy of equipment operation, and the material is tempered to increase its wear resistance. It is widely used in automatic linear transmission, woodworking cutting machines and various light-load transmission machinery.

Frequently Bought Together

Professional Service

Exclusive Customization

Industry-Leading Innovation

Reliable manufacturer

Linear Rack and Pinion Features

√High precision grade, in line with DIN 8 grade precision standard

√Made of high-strength alloy steel or stainless steel

√Precision milling process, accurate tooth profile

√Long service life

√Able to withstand large radial and axial loads, suitable for heavy and high load scenarios

√Standardized design, compatible with other DIN standard gears and transmission components

√Low noise operation, suitable for environments with high noise requirements

Specification parameter of linear ratchet rack DIN 8

Click the download button to get the specification sheet of the metal linear rack DIN 8.

Click the download PDF

Specification parameter of linear rack DIN 8

Parameter Configuration

Specification	Value
Type	Spur/Helical Rack
Module	2/3/4/5
Gear Grinding Accuracy	German Standard DIN 8
Material	C45
Hardness	HRC24-27
Heat Treatment	Quenching and Tempering

Hardness Comparison

DIN8 precision gear rack hardness HRC24-27, DIN 6 hardness HRC50-55, fine milling and tempering racks DIN 8 and DIN 6 racks have significant differences in hardness and performance.

Surface Treatment of New Rack and Pinion

Galvanizing: Effectively prevents rust and is suitable for humid environments. Improves surface hardness and enhances wear resistance.
Blackening: Forms an oxide film to provide anti-rust protection.
Chrome plating: Significantly improves wear resistance and is suitable for high-load applications.
Nickel plating: Improves surface hardness and enhances wear resistance.
Quenching and tempering: Significantly enhances strength and toughness.

Product Advantage

High Precision

DIN8 grade linear racks have strict manufacturing tolerances to ensure accurate tooth shape and pitch, suitable for high-precision applications.

Tempering treatment

After tempering treatment, the hardness and toughness of the CNC gear rack are improved, and the wear resistance and impact resistance are enhanced.

High Transmission Efficiency

High-precision linear racks combined with corresponding gears can achieve higher transmission efficiency and reduce energy loss.

Surface Treatment

The linear racks are case hardened for increased wear and corrosion resistance.

How Linear Motion Works?

The gear rotates under the drive of the motor and transmits the rotational motion to the linear rack.
The rotational force of the gear pushes the rack to move in a linear direction, realizing the conversion from rotation to linear motion.
By changing the rotation direction of the gear, the movement direction of the rack is controlled.
